Cartes de développement du laboratoire d’Informatique de l’ESIEE
Mars 2010
52223 IAR (rouge) Lcd, Led (32Ko RAM, 60Mhz)
52231 : digibutler Elektor (32Ko RAM, 60Mhz)
JMBADGE board : accéléro, led matrix: MCF51JM128(16Ko RAM, 33Mhz-32bits)
CSM12C32: µC MC9S12c32 sur minicarte (2Ko RAM, 8Mhz)
MPS430 – Ez430 F2013 DSP (2ko Flash, 128o RAM,16Mhz)
MCF 5282 : M5282 Lite Freescale: CML(16Mo RAM, 60Mhz)
MCF 52259 : M52259 EVB (64Ko+512Ko RAM, 80MHz)
MCF 5484 : Zoom coldfire lite dev. kit M548x EVB (64Mb SDRAM, 200MHz)
Carte EDB9307 : ARM9 512MB RAM avec sortie vidéo
Carte iMx21 avec écran LCD pour linux
OMAP 1510 Innovator avec ecran LCD
DSP TMS320C6711 : IEK 6711 ATEME
Les cartes CSM12C32, M5282, M52259 EVB, M548x EVB, MS5485 EVB GHS, iMX21 ont été gracieusement mise à disposition par la société Freescale
Les cartes MSP 430 et DM6437 ont été mise à disposition par la société Texas Instrument.
Les cartes IEK 6711 ont été mise à disposition par la société ATEME.
Carte à microcontrolleurs
52223 IAR (rouge) Lcd, Led (32Ko RAM, 60Mhz), buzer, touches, ADC, LCD 2lignes, lecteur SD, environnement IAR
• MCF52223 : 256K Flash, 32Ko SRAM
• Power-supply LED
• Reset button
• External power or power via J-Link; jumper selectable
• JTAG-BDM26 connector
• PWM to buzzer
• I2C routed to header pins
• 3 UART connectors (DB9)
• SPI routed to header pins
• ADC to potentiometer
• LCD screen
• 16 LEDs (GPIO)
• Prototype area
• 4 buttons (GPIO)
• USB connector (OTG/host - jumper selectable)
• SD/MMC-socket
Boitier 100 LQFP / 8$ Digi.
52231 : digibutler Elektor (32Ko RAM, 60Mhz)
carte a tout faire elektor mais pas de bus systeme (famille 52230 à 236)
LQFP 80 (existe en
112)- 60Mhz, 128K Flash /32k SRAM,ADC, GPIO
- 8 entrees Analogiques
- 4 GPIO (56 GPIO possibles)
- 1 interface I2C
- Ethernet
- PAS DISPO DIGIK. (mini commande 90 !)
JMBADGE board : accéléro, led matrix: MCF51JM128(16Ko RAM, 33Mhz-32bits)
· MCF51JM128RM ColdFire V1 microcontroller 12K Fmash / 16k RAM
- Two serial communications interfaces (SCI)
- Two serial peripheral interfaces (SPI)
- Cryptographic acceleration unit (CAU)
- Random number generator accelerator (RNGA)
- Analog comparators
- Analog‐to‐digital converter (ADC)
- Two I2C interfaces
Carrier modulation timer
(CMT) - Two timer modules (TPM)
- Up to 66 GPIOs and 16 Rapid GPIOs
· Powered by USB or rechargeable battery
· USB device interface
· Three‐axis accelerometer
· Capacitive touch sensor with 8 touch points
· LED matrix display
· SD card slot
· Magnetic Buzzer
· Dispo 8$ Digik.
CSM12C32: µC MC9S12c32 sur minicarte (2Ko RAM, 8Mhz)
enfichable sur carte a prototyper inconv. : pb de circuit imprimer si on veux l'utiliser pour nos appli., que des versions LFQP
* MC9S12C32 MCU, 48 QFP
o 32K Byte Flash EEPROM
o 2K Bytes RAM
o 31 I/O lines
o Timer/PWM
o SCI and SPI Communications Ports
o Key Wake-up Port
o BDM DEBUG Port
o CAN 2.0 Module
o Analog Comparator
o 8 Mhz Internal Bus Operation Default
o 25 MHz Bus Operation using internal PLL
* Regulated +5V power supply w/ 2.0 mm Barrel Connector
* Power Selection Jumper
o Optional power input from Connector J1
o Optional power output through Connector J1
* 40 pin connector provides access to most MCU I/O signals
* 16 MHz Ceramic Resonator
* RS-232 Serial Port w/ DB9 Connector
* 8-Ch, 10-bit, Analog Comparator with rail-to-rail operation and external trigger capability
* 8-Ch, 16-bit Timer with Input Capture, Output Compare, and PWM capabilities
* User Components Provided
o 3 Push Button Switches: 2 User, RESET
o 3 LED Indicators: 2 User, VDD
* Jumpers
o Disable User Functions
o Power Select
* Connectors
o 40-pin MCU I/O Connector
o 2.0mm Barrel Connector Power Input
o DEBUG BDM Connector
o DB9 Communications Connector
*Dispo $9 Digik.
MPS430 – Ez430 F2013 DSP (2ko Flash, 128o RAM,16Mhz)
- 10 GPIO
8
ADC- Kit Dispo. $20 Dig.
Cartes à microprocesseurs
MCF 5282 : M5282 Lite Freescale: CML(16Mo RAM, 60Mhz) 5282 (Le Candidat de remplacement pour les 68332 de IN201/IN101)
# 60Mhz
# 16M byte SDRAM, 2M byte Flash
# 10/100 Ethernet PHY and RJ45 connector
# 3 UARTs with DMA capability
# QSPI
# I²C
# Queued serial peripheral interface (QSPI) with four peripheral chip selects
# QADC: 8-channel 10-bit queued analog-to-digital converter
# Four 32-bit timers with capture, compare and DMA capability
# Eight 16-bit timer channels for capture, compare, and pulse width modulation
# PITs: 4
# Bus processeur
MCF 52259 : M52259 EVB (64Ko+512Ko RAM, 80MHz)
Fast
Ethernet Controller connected to external PHY- USB Support
- Crystal/Clock
- BDM/JTAG
- Three UARTs
- Eight-channel 12-bit fast analog-to-digital converter with simultaneous sampling
- FlexBus external bus interface available on 144 pin
- Timers
- External Interrupts
- CAN Support
- University Breakout Connector for serial interfaces (I2C, QSPI, GPIO, etc.)
- On-chip 64K SRAM
- On-chip 512K Flash
- On board 512KB MRAM
MCF 5484 : Zoom coldfire
lite dev. kit M548x EVB (64Mb SDRAM, 200MHz)
- M5484 Fire Engine Module (SOM-ETX), including:
- MCF5484CZP200 Processor
- 64MB DDR-SDRAM
- 4MB Flash
- Two 10/100 RJ45 Ethernet connectors
- One PCI slot (32 bit, 33 or 66MHz, 3.3V)
- One CAN Interface
- Serial Ports
- One RS-232 Serial Port
- USB 2.0
- One High Speed Device (on Fire Engine)
- Linux BSP
- v2.4.26 Kernel
- Core Tools
- Open Source Compiler
- Serial, I2C, DSPI, Ethernet, USB, and PCI drivers
MCF
5329 : M5329EVB (32Mb RAM,240MHz, 211Mips) : (utilisée pour
projet TG I4 2010)
- MCF5329 based Fire Engine Module
- MCF5329CVM240 Processor
- 32 MB DDR-SDRAM
- 2 MB Boot Flash
- 16 MB NAND Flash
- LCD Display Interface
- Touch Screen Controller
- 10/100 Ethernet
- Audio Codec
- Integrated LCD Touch and Backlight connector
- 10/100 RJ45 Ethernet Connector
- USB Host Physical Interface
- USB On-the-go Physical Interface
- CAN Physical Interface and standard DB9 Connectors
- Audio I/O
- Compact Flash
- RS-232 Serial Ports (2)
- BDM/JTAG Interface
MCF 5485 : MS5485 EVB GHS
· ColdM5485CFE Fire Engine Module (SOM-ETX), including:
· MCF5485CZP200 Processor
· 64MB DDR-SDRAM
· 16MB Flash
· Graphics Controller
· USB Host Controller
· LCD Display Connector - includes integrated LCD, touch, and backlight connector for Display Kits
· DVI Connector
· Two 10/100 RJ45 Ethernet connectors
· Two PCI slots (32 bit, 33 or 66MHz, 3.3V)
· Serial Ports (Two RS-232 Serial Ports , Two TTL Serial Ports)
· Two CAN 2.0B Interfaces
· USB 2.0 (One High Speed Device (on Fire Engine), Four High Speed Host ports)
· SPI
· RTC
Carte EDB9307 : ARM9 512MB RAM avec sortie vidéo
Carte iMx21 avec écran LCD pour linux
(projet I4 TG 2006)
OMAP 1510 Innovator avec ecran LCD
DSP TMS320C6437 : DM6437 EVM
(pour les TPs)
DSP TMS320C6711 : IEK 6711 ATEME
(Pour les TPs)
Cartes FPGA
ML506
ML507
Spartan 3
Spartan 2
Carte XUPV Virtex Pro 2
